روتر سیسکو مدل ۱۹۴۱

روتر سیسکو مدل ۱۹۴۱

روتر سیسکو مدل ۱۹۴۱

8،000،000 تومان

8 عدد در انبار

شناسه محصول: روتر سیسکو مدل ۱۹۴۱ Categories: , , برند: ,

توضیحات

مشخصات فنی روتر سیسکو Cisco 1941-K9:



SPECIFICATIONS
Cisco Systems, Inc Manufacturer
CISCO1941/K9 Manufacturer Part Number
Router Product Type
External – modular – 2U Form Factor
34.3cm x 29.2 cm x 8.9 cm Dimensions (WxDxH)
5.8kg Weight
512MB (installed) / 2 GB (max) DRAM Memory
256MB (installed) / 8 GB (max) Flash Memory
OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing Routing Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet Data Link Protocol
IPSec Network / Transport Protocol
SNMP, RMON Remote Management Protocol
Cisco IOS IP Base , firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED) Features
IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag Compliant Standards
AC 120/230 V ( 50/60 Hz Power
Services and Slot Density
Yes Embedded hardware-based crypto acceleration (IPSec + SSL)
2 Total Onboard LAN 10/100/1000
2 RJ-45-Based Ports
0 SFP-Based Ports
0 SM Slots
0 Double-Wide SM Slots
2 EHWIC Slots
1 Double-Wide EHWIC slots (use of a double- wide EHWIC slot will consume two EHWIC slots)
1 (0 on the Cisco 1941W) ISM Slots
512MB Memory (DDR2 Error Correction Code [ECC] ECC DRAM) – Default
2.0GB Memory (DDR2 ECC DRAM) – Maximum
slot 0: 256 MB
slot 1: none		 Compact Flash (external) – Default
slot 0: 4 GB
slot 1: 4 GB		 Compact Flash (external) – Maximum
2 External USB flash memory slots (Type A)
1 USB Console Port (Type B) (up to 115.2 kbps)
1 Serial Console Port (up to 115.2 kbps)
1 Serial Auxiliary Port (up to 115.2 kbps
AC, POE Power Supply Options
No Redundant Power Supply Support
Power Specifications
100-240 V ~ AC Input Voltage
47-63 Hz AC Input Frequency
1.5-0.6 AC Input Current range AC Power Supply (Max) (Amps)
<50 A AC Input Surge Current
35W Typical Power (No Modules)
110W Maximum Power capacity with AC power supply
110W Maximum Power capacity with PoE power supply (platform only)
80W Maximum PoE device power capacity with PoE power supply
Physical Specifications
3.5in x 13.5 in x 11.5 in (34.3 cm x 29.2 cm x 8.9 cm) Dimensions (H x W x D)
2RU Rack Height
Included Rack-mount 19in. (48.3 cm) EIA
Yes Wall-mount (refer to installation guide for approved orientation)
23.1lbs (10.48 Kg) Package Weight
12lbs(5.44 Kg) Weight-with AC power supply (no modules)
12.8lbs (5.8 Kg) Weight-with POE power supply (no modules)
14lbs (6.35 Kg) Maximum Weight-Fully Configured
Front to Side Airflow
Environmental Specifications
Operating Condition
0-40°C (32-104°F) Temperature-5906 feet (1800 m) max. altitude
0-25°C (32-77°F) Temperature-9843 feet (3000 m) max. altitude
3000 m (10000 ft) Altitude
10to 85% RH Humidity
26/46dBA Acoustic: Sound Pressure (Typ/Max)
36/55dBA Acoustic: Sound Power (Typ/Max)
Transportation/Storage Condition
40-70°C- Temperature
5to 95%RH Humidity
4570m (15000 ft) Altitude
Regulatory Compliance
UL 60950-1
CAN/CSA C22.2 No. 60950-1 EN 60950-1
AS/NZS 60950-1
IEC 60950-1		 Safety
47 CFR, Part 15 ICES-003 Class A
EN55022 Class A CISPR22 Class A AS/NZS 3548 Class A VCCI V-3
CNS 13438
EN 300-386
EN 61000 (Immunity)
EN 55024, CISPR 24 EN50082-1		 EMC
TIA/EIA/IS-968 CS-03
ANSI T1.101
ITU-T G.823, G.824 IEEE 802.3
RTTE Directive		 Telecom
